Film capacitor product list

Summary	Features	Rated Voltage	Capacitance（μF）	Temp. range （℃）	Series Code	Style
General use	Standard	250VDC 450VDC 630VDC 800VDC 1250VDC	0.47～10 0.22～4.7 0.068～2.2 0.68～2.2 0.001～0.47	-40～+85 (+105)	FPB info
	Small NEW	630VDC	0.47～2.2	-40～+105	FPB2 info
	Box Small NEW	630VDC	1.0～2.2	-40～+105	FPCS info
	High Temp. Small	630VDC	0.068～2.2	-40～+105 (+125)	FPT2 info
	High Temp.	630VDC	0.01～0.047	-40～+105 (+125)	FPT info
	Standard	250VDC 450VDC 630VDC	0.01～0.33 0.01～0.15 0.015～0.047	-40～+85 (+105)	MDX info
	5,7.5mm Lead pitch	50VDC 250VDC	0.1～2.2 0.01～0.15	-40～+85 (+105)	MDD info
	Large capacitance	35VDC 63VDC	4.7～22 10～22	-40～+85 (+105)	MDL info
	High Voltage	500VAC	0.0022～0.1	-40～+85 (+105)	MDD info
Power supply for PFC (Halogen-free Low Noise) General use	Small Box NEW	450VDC	0.47～4.7	-40～+85 (+110)	FPCS info
	Small NEW	450VDC	0.47～2.2	-40～+85 (+110)	FPS5 info
	Small	450VDC	0.47～4.7	-40～+85 (+110)	FPS4 info
	Standard	450VDC	0.47～2.2	-40～+85 (+110)	FPS3 info
	550V	550VDC	0.47～2.2	-40～+85 (+110)	FPA info
Large Current High Frequency use	Large Current	250VDC 450VDC 630VDC	0.01～10 0.01～3.3 0.01～2.2	-40～+85 (+105)	FPF info
Class-X2	X2	310VAC	0.01～10	-40～+110	FSX Please contact us
Across-the-line use	Standard	125VAC 250VAC	0.033～4.7 0.01～2.2	-40～+85 (+105)	CFD-N info
Surge absorbar C-R units	C-R Not recommended	125VAC 250VAC	0.1µF+120 Ω 0.033µF+120 Ω	-40～+85	CR info

Capacitors for Power Electronics

Summary	Features	Rated Voltage	Capacitance (μF)	Temp. range (℃)	Series Code	Style
General use (DC-Link, Smoothing, etc)	Long Life High Voltage Large Current	630VDC 800VDC 1100VDC 1300VDC	5～65 10～20 1～25 1～15	-40～+70 (+85)	FPCL info
